3M™ Scotchlok™ Electrical Insulation Displacement Connector (IDC), 567, run and tap, brown, 18-14 AWG (tap), 12-10 AWG (run), box

Manufacturer: 3M | Catalog # 562-BOX | Electrozad South Part # 230109
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet
Use 3M™ Scotchlok™ Electrical IDC 567 to electrically connect a wire end (tap) to a through (run) wire and insulate the connection. It has a maximum insulation O.D. diameter of 0.145 inches (3.68 mm), and a tap of 0.190 inches (4.82 mm). This product also features a run and operating temperature of 221..F (105..C). The suggested application tool for the 3M™ Scotchlok™ Electrical IDC 567 is the 3M™ Scotchlok™ Crimping Tool E-9BM.

Technical Information

Applications
For Low-Voltage Applications
Cable Size
12 AWG Solid/Stranded - 10 AWG Stranded
Cable Type
Solid/Stranded
Conductor Size
10 AWG
Connection Type
Double Run Or Tap
Contact Material
Brass
Flame Retardant
Yes
Material
Polypropylene,Tinned Brass
Type
Self-Stripping, Fully Insulated

Manufacturer Information

Brand
3M
Sub Brand
Scotchlok™

General Product Info

12-Digit UPC
054007110323
Color
Yellow
GTIN
10054007110320
Housing Material
Flame Retardant Polypropylene
