Receptacle duplex flush rtp 15A L5-15R brown

Manufacturer: Hubbell Wiring Devices | Catalog # HBL4794 | Electrozad South Part # 290803
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page Installation / Instruction Manual Technical Drawing Manufacturer Warranty
Heavy duty specification grade combination face duplex receptacle made of RTP face with two feeds one return, 125 V, side wire.

Technical Information

Amperage
15 A
Applications
For Heavy Duty Applications
Base Material
Plastic,RTP
Conductor Size
14-12 AWG
Current
15 A
Dielectric Strength
Withstands 2,000V minimum
Face Material
Polyester
Horsepower
0.5 hp
Material
Thermoplastic
Mounting Type
Flush/Recessed/Screw
NEMA
5-15R
Number of Poles
2
Number of Wires
3
Operating Temperature
-40 degrees C
Size
Standard
Standard
C22.2,CSA,No. 42 File 285,UL,UL498 File E2186
TC Connection
Screw Terminal
Type
Locking, Straight Blade
Voltage
2,000 V
Wattage
1875 W
Wire Count
3
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device Kellems
Sub Brand
Straight Blade

General Product Info

12-Digit UPC
783585237008
Color
Black
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
GTIN
00783585237008
Weight
0.25 lb

Dimensions

Height
0.88 in
Length
3.28 in
Width
1.5 in

Certifications & Compliance

Country of Origin
Puerto Rico
